| Place of Origin | CHINA |
| Brand Name | DAWNERGY |
| Certification | RoSH |
| Model Number | 40+1CH Gaussian AAWG Spec |
The Fiber Optic Passive Components operates within the C21~C60 Operating Band, making it compatible with a wide range of Fiber Optic Active Components.
Designed for ease of use, the Fiber Optic Passive Components requires no external power source and can be easily installed into your Fiber Optic Cabinet or Fiber Optic Box. Its compact size also ensures that it won't take up too much space in your setup.
Whether you're setting up a new Fiber Optic network or upgrading an existing one, the Fiber Optic Passive Components is a reliable and cost-effective solution for all your signal transmission needs. Order yours today!
| Parameters | Specifications | Unit |
| Pass Band Profile | Gaussian | |
| Number of Channels | 40 | CH |
| Number Channel Spacing | 100 | GHz |
| Operating Band | C21~C60 | |
| Clear Passband | ±12.5 | GHz |
| Wavelength Stability | ±50 | pm |
| 1dB Channel Bandwidth | ≥0.23 | nm |
| 3dB Channel Bandwidth | ≥0.41 | nm |
| Insertion Loss cross full passband and including connector loss | ≤3.6 | dB |
| Ripple | ≤2 | dB |
| Adjacent Channel Isolation | ≥25 | dB |
| Non-Adjacent Channel Isolation | ≥30 | dB |
| Total Crosstalk | ≥22 | dB |
| Insertion Loss Uniformity | ≤1.2 | dB |
| Directivity(Mux Only) | ≥40 | dB |
The Fiber Optic Passive Components are designed to provide exceptional performance and reliability. The product is equipped with features such as a polarization mode dispersion of ≤0.5dB and adjacent channel isolation of ≥25dB. The connector type for this product is LC/UPC and the ripple is ≤2dB. The 1dB channel bandwidth is ≥0.23nm.
The Fiber Optic Passive Components are ideal for various product application occasions and scenarios. The product can be used in Fiber Optic Active Components, Fiber Optic Isolator, and Fiber Optic Sensors. The product is highly versatile and can be used in many different industries such as telecommunications, data centers, military, and medical.
With its exceptional performance, high reliability, and versatile use, the Fiber Optic Passive Components from DAWNERGY are an excellent choice for many different fiber optic communication applications. With its high supply ability and efficient delivery times, DAWNERGY is a reliable partner for all your fiber optic communication needs.
Our Fiber Optic Passive Components are designed to provide high-quality optical performance and reliability in various applications. Our technical support and services for this product include:
We are committed to providing exceptional customer service and technical expertise to ensure the success of your fiber optic projects.
